HCLX-PV Smart Photovoltaic DC Combiner Box

产品概述  Overview

HCLX-PV 智能光伏直流汇流箱是将24 路光伏电池组件串的直流输入汇流合成1 路或多路输出，每路配熔断丝，输出配备防雷器和断路器，大大简化了直流配电柜及逆变器的输入接线。提供防雷保护，短路保护和接地保护。汇流箱分为智能和非智能两种类型。智能直流汇流箱内部装有汇流监测单元，能监测每路光伏电池串输入的电流、汇总输出电压、箱体内的温度及防雷器状态、断路器状态等。

该装置内部布置简洁明了，布线整齐合理。可靠性高，维护简单。户外壁挂式安装，能适应各种恶劣环境。除了相关核心元器件外，其他可按用户要求定制。

HCLX-PV intelligent photovoltaic DC combiner box combines up to 24 DC input combiners of photovoltaic cell modules into one or multiple outputs, each with a fuse, and the output is equipped with lightning protection devices and circuit breakers, greatly simplifying the input wiring of DC distribution cabinets and inverters. Provide lightning protection, short circuit protection, and grounding protection. The combiner box is divided into two types: intelligent and non intelligent. The intelligent DC combiner box is equipped with a combiner monitoring unit inside, which can monitor the input current of each photovoltaic battery  string, summarize the output voltage, temperature inside the box, lightning protection status, circuit breaker status, etc.

The internal layout of the device is simple and clear, and the wiring is neat and reasonable. High reliability and easy maintenance. Outdoor wall mounted installation, able to adapt to various harsh environments. In addition to related core components, others can be customized according to user requirements.
