HCLX-AC Photovoltaic AC Combiner Box
HCLX-AC photovoltaic AC combiner box is an important component used in photovoltaic series power generation systems to undertake series inverters, AC distribution cabinets, or step-up transformers. The incoming line of this combiner box uses a circuit breaker input, the output uses a circuit breaker or load isolation switch, and the busbar is protected against secondary lightning protection after converging, The maximum rated voltage of the system is AC800V.
Detail
产品概述 Overview
HCLX-AC 光伏交流汇流箱是适用于光伏组串式发电系统中，承接组串式逆变器与交流配电柜或升压变压器的重要组成部分，此汇流箱的进线采用断路器输入，输出采用断路器或负荷隔离开关，母线汇流后采用二级防雷保护，系统额定电压为AC800V．防护等级与组串式逆变器同级为IP65．达到室外安装的要求，满足防水，防尘、防紫外线，防盐雾腐蚀等。
该产品大大简化了组串式逆变器与交流配电柜或升压变压器之间的接线，此产品内部结构简洁明了，布线整齐合理。可靠性高，维护简单。户外壁挂式安装，能适应各种恶劣环境。除了标准材质和尺寸外，可按用户要求定制。
HCLX-AC photovoltaic AC combiner box is an important component used in photovoltaic series power generation systems to undertake series inverters, AC distribution cabinets, or step-up transformers. The incoming line of this combiner box uses a circuit breaker input, the output uses a circuit breaker or load isolation switch, and the busbar is protected against secondary lightning protection after converging, The maximum rated voltage of the system is AC800V. The protection level is IP65, which is the same as the series inverter. It meets the requirements for outdoor installation and meets the requirements of waterproofing, dust prevention, UV protection, salt spray corrosion prevention, etc.
This product greatly simplifies the wiring between the series inverter and the AC distribution cabinet or step-up transformer. The internal structure of this product is simple and clear, and the wiring is neat and reasonable. High reliability and easy maintenance. Outdoor wall mounted installation, able to adapt to various harsh environments. In addition to standard materials and sizes, it can be customized according to user requirements.
